PORTABLE METAL BANDSAW 2.2HP 170MM

 New and improved website Freight Free

Enquiry
PORTABLE METAL BANDSAW 2.2HP 170MM
Click on image for larger photo
Product Code: B005

PORTABLE METAL BANDSAW 2.2HP MOTOR VARY
SPEED 30 TO 80MPM - SWIVEL HEAD TO 60%-
CUTS 170MM X 170MM WEIGHT IS ONLY 38KG
Border Image Border Image
Shop Price: $1,449.00
Web Price: $1,449.00  inc tax

Availability: In Stock
Quantity:
Weight: 43 KG
Border Image Border Image

Specifications:

Operation Type Swivel Head
(mm)Round @ 90º170
(mm)Round @ 45º125
(mm)Round @ 60º75
(mm)Square @ 90º170
(mm)Square @ 45º125
(mm)Square @ 60º70
(mm)Rectangle (W x H) @ 90º170 x 170
(mm)Rectangle (W x H) @ 45º125 x 125
(mm)Rectangle (W x H) @ 60º75 x 70
(mm)Table Working Height137
Cutting Head Beam TypeManual Return
Cutting Head Beam ReturnSpring Assist Return
Cutting Head Down Feed ControlManual
Vice Clamping FixtureManual
(m/min)Blade Steps / SpeedsVariable 30-80
(mm)Blade Size (L x W x T)2035 x 19 x 0.8
(kW / hp)Motor Power1.65 / 2.2
(V / amp)Voltage / Amperage240 / 10
(kg)Nett Weight38

Description:

The B005 swivel head metal cutting band saw is the bigger brother from the B004 family and only 38kg it is still easily portable onto job sites. It is very suitable for the home model engineer where space may be tight but an accurate machine is required. Constructed mainly from cast alloy and steel, it has a very rigid bow that enables a high degree of tension to be applied to the blade and accepts a 19mm wide blade for durable & accurate cutting. The whole bow and motor assembly can be swivelled from 0° to 60° to create accurate mitre cuts.

The blade is firmly guided by double ball bearing and is driven via the direct drive motor fitted with variable speed, so the blade speed can be adjusted to suit the task in hand. The conveniently located hand trigger switch on the bow and a spring system supports the weight of the bow during operation. This is a compact and very well made machine and it can be relied on to deliver an accurate cut every time.

Features:

*Compact & portable design for the smaller workshop where space is at a premium
*19mm wide variable pitch M42 bi-metal blade for increased accuracy & durability
*Electronic variable blade speed 30-80mpm
*Swivel head to 60º using calibrated scale
*Adjustable double ball bearing blade guides
*Cast aluminium base & saw bow frame
*Quiet running, direct drive, variable speed motor
*Operational handle with start trigger switch
*Adjustable length stop for repetition cutting
*Safety magnetic main power switch
*1.65kW / 2.2hp 240V motor
*Blade Size (L x W x T)2035 x 19 x 0.8
