Product Code:
9633
6 PAIRS BALL TYPE END EXTRACTOR HEADS
SIZES: 16, 19, 22, 25, 28 & 32MM - PULL
BEARING BY DRILLING CAGE & INSERT BALL
|
|
|
|
|
Please enter a valid quantity |
|
|
|
|
 |
|
|
|
NOTE - THIS TYPE OF PULLER IS MADE FOR REMOVING BALL BEARING TYPE BEARINGS WHEN YOU CAN NOT GRAB THEM WITH A NORMAL PULLER FROM
INSIDE OR OUTSIDE THE SITUATION IS YOU HAVE A HOUSING ON THE OUTSIDE AND A SHAFT THROUGH THE BEARING,SO WITH THIS TYPE OF PULLER
YOU DRILL THE BEARING CAGE EACH SIDE OF THE BEARING PUSH THE BALL BEARING TO THE SIDE & THEN PICK THE RIGHT SIZE BALL END ( SAME SIZE AS THE BEARING BALL) AND INSERT THE BALL END SIDEWAYS THEN TURN IT TO TOCK IT INTO POSITION SCREW THE PULLER ARMS ON TO BALL END & SET YOUR PULLER UP THIS WILL GIVE YOU EVEN TENSION ON THE INNER & OUTER BEARING RINGS WHEN PULLING THE BEARING
THIS BEARING EXTRACTOR KIT CAN REMOVE BEARINGS WITHOUT THE NEED TO DISMANTLE MACHINERY OR REMOVE THE RUNNING SHAFT. POSITIVE SEATING ALLOWS AN EVEN TENSION ON THE INNER AND OUTER BEARING RINGS, REDUCING FRICTION AND RESISTANCE.
BEARING EXTRACTOR KIT:
CAPACITY: 55-220MM. REMOVES BEARINGS WITHOUT THE NEED TO DISMANTLE MACHINERY OR REMOVE THE RUNNING SHAFT.
POSITIVE SEATING ALLOWS AN EVEN TENSION ON THE INNER & OUTER BEARING RINGS, REDUCING FRICTION & RESISTANCE.
CROSS BLOCK LENGTH: 240MM, MAIN PULLING RODS: 330MM PULLING RODS EXTENSIONS: 275MM, FORCING SCREW: 0.8125MM UNF X 14TPI X 305MM LONG, SPREAD: 70-190MM, REACH: 490MM
SUIT BEARING NO 6021 TO 6032 6212 TO 6230 6309 TO 6321 6406 TO 6417
|
