*K*INJECTION 17 TON NOZZLE PULLER DIESEL
Click on image for larger photo
Product Code: 4055

*K*INJECTION 17 TON NOZZLE PULLER DIESEL
ENGINES-THREADS FROM 14MM TO 25MM - 15MM
STROKE 15.5MM BORE LOW HEIGHT 89MM
Border Image Border Image
Shop Price: $499.00
Web Price: $499.00  inc tax
Shipping charges may vary and are subject to change based on product dimensions and destination.

Availability: On Order
Quantity:
Weight: 7 KG
Border Image Border Image
THIS SET ENABLES THE PROFESSIONAL SAFE EXTRACTION OF VERY TIGHT FITTING INJECTION NOZZLES IN CONJUNCTION WITH A SPECIAL PULL SPINDLE. AN INJECTION NOZZLE PULLER WITH AN EXTRACTION BRIDGE AND A HYDRAULIC PUMP WITH A MANOMETER.

THE HYDRAULIC CYLINDER WITH SHOULDER NUT TOGETHER WITH A SPECIAL PULL SPINDLE IS PLACED ONTO THE EXTRACTION BRIDGE INSTEAD OF A MECHANICAL DRIVE. THE SPECIAL MANOMETER OF THE HYDRAULIC PUMP ENSURES THAT THE APPLIED FORCE CAN CHECKED DURING THE EXTRACTION PROCESS.

CONTAINS:
- 1 X 14MM X 1.5 PITCH PULLING SPINDLE 240MM LONG.
- 1 X 14MM X 1.5 PITCH PULLING SPINDLE 315MM LONG.
- 1 X 17MM X 1.0 PITCH PULLING SPINDLE 240MM LONG.
- 1 X 17MM X 1.0 PITCH PULLING SPINDLE 315MM LONG.
- 1 X 18MM X 1.5 PITCH PULLING SPINDLE 315MM LONG.
- 1 X 25MM X 1.0 PITCH PULLING SPINDLE 240MM LONG.
- 1 X DISTANCE RING
- 1 X TOOTH CAP NUT 16MM
- 1 X BUSH
- HYDRAULIC RAM: 170KN (17 TON), 15MM STROKE, 16.5MM BORE IN TUBULAR PISTON.
