TAP & DIE SET 60 PCE METRIC-UNF-NPT

New and improved website Freight Free

Enquiry

TAP & DIE SET 60 PCE METRIC-UNF-NPT
Click on image for larger photo
Product Code: 12009

60 PCE TAP & DIE SET - UNF UNC & METRIC.
TAP & DIE SET 60 PCE METRIC-UNF-NPT
Border Image Border Image
Shop Price: $159.00
Web Price: $159.00  inc tax

Availability: Out of stock
Quantity:
Weight: 6.18 KG
Border Image Border Image
TAP & DIE SET MET, UNC, UNF & NPT 60PC

METRIC SIZES
TAP SIZES Ø DIE SIZES DIE DIAMETER PITCH TAPPING LENGTH DRILL SIZE
3MM 3MM 25MM 0.5MM 18MM 2.5MM
4MM 4MM 25MM 0.7MM 20MM 3.3MM
5MM 5MM 25MM 0.8MM 22MM 4.2MM
6MM 6MM 25MM 1.0MM 24MM 5.0MM
7MM 7MM 25MM 1.0MM 26MM 6.0MM
8MM 8MM 25MM 1.25MM 30MM 6.8MM
9MM 9MM 25MM 1.25MM 30MM 7.8MM
10MM 10MM 25MM 1.5MM 32MM 8.0MM
10MM 10MM 25MM 1.0MM 32MM 9.0MM
12MM 12MM 25MM 1.75MM 36MM 10.3MM

UNC SIZES
TAP SIZES Ø DIE SIZES DIE DIAMETER PITCH TAPPING LENGTH DRILL SIZE
#4 #4 25MM 40 TPI 16MM #43 - 2.3MM
#6 #6 25MM 32 TPI 18MM #36 - 2.7MM
#8 #8 25MM 32 TPI 20MM #29 - 3.45MM
#10 #10 25MM 24 TPI 22MM #25 - 3.8MM
#12 #12 25MM 24 TPI 22MM #16 - 4.5MM
1/4" 1/4" 25MM 20 TPI 24MM #7 - 5.1MM
5/16" 5/16" 25MM 18 TPI 30MM 17/64" - 6.5MM
3/8" 3/8" 25MM 16 TPI 35MM 5/16" - 7.9MM
7/16" 7/16" 25MM 14 TPI 38MM 3/8" - 9.4MM
1/2" 1/2" 25MM 13 TPI 42MM 27/64" - 10.7MM

UNF SIZES
UNF TAP SIZES Ø UNF DIE SIZES UNF DIE DIAMETER UNF PITCH UNF TAPPING LENGTH UNF DRILL SIZE
#10 #10 25MM 32 TPI 22MM #21 - 4.0MM
1/4" 1/4" 25MM 28 TPI 24MM #3 - 5.4MM
5/16" 5/16" 25MM 24 TPI 30MM 17/64" - 6.9MM
3/8" 3/8" 25MM 24 TPI 35MM 21/64" - 8.4MM
7/16" 7/16" 25MM 20 TPI 38MM 25/64" - 9.9MM
1/2" 1/2" 25MM 20 TPI 42MM 29/64" - 11.5MM

NPT SIZES
TAP SIZES Ø DIE SIZES DIE DIAMETER PITCH TAPPING LENGTH DRILL SIZE
1/8" 1/8" 25MM HEX 27 TPI 55MM 8.7MM

ACCESSORIES:
BAR TYPE TAP WRENCH 1/2" CAPACITY
2 SCREW PITCH GAUGES
T TYPE TAP WRENCH 1/4" CAPACITY
1" OD DIE HANDLE
SCREWDRIVER
