Product Code:
IC8-24
BATTERY CHARGER 24 VOLT 8 AMP 7 STAGE
ALL TYPES BATTRIES - INPUT POWER: 480W
ADJUSTABLE CURRENT - INTELLI-CHARGE
|
|
|
|
|
Please enter a valid quantity |
|
|
|
|
 |
|
|
|
7 STAGE CHARGING - INTELLI-CHARGE BATTERY CHARGERS USE INTELLIGENT ELECTRONICS TO MONITOR THE CHARGING PROCESS AND DELIVER AN ADVANCED 7-STAGE CHARGE TO YOUR BATTERY. 7-STAGE CHARGING IS A VERY COMPREHENSIVE AND ACCURATE CHARGING TECHNIQUE THAT GIVES YOUR BATTERY LONGER LIFE AND BETTER PERFORMANCE COMPARED TO USING TRADITIONAL CHARGERS.
MULTI CHEMISTRY - THE MULTI CHEMISTRY FUNCTION ALLOWS YOU TO SET THE CHARGING PROFILE TO SUIT THE BATTERY?S CHEMISTRY TYPE (GEL, AGM, WET AND CALCIUM). THIS ENSURES CORRECT AND THOROUGH CHARGING AND MAXIMISES BATTERY PERFORMANCE AND BATTERY LIFE.
ADJUSTABLE CURRENT - INTELLI-CHARGE ALLOWS YOU TO ADJUST AND SELECT THE CHARGE RATE FROM AS LOW AS 2 AMPS TO BEST SUIT THE SIZE OF YOUR BATTERIES.
POWER SUPPLY - IN THE LARGER MODELS (25, 35, 50A, 8A/24V), POWER SUPPLY OPERATES AS A FLOAT CHARGE (CONSTANT VOLTAGE) AND IS IDEAL FOR MAINTAINING A BATTERY WHILE RUNNING AN APPLIANCE OR LOAD FROM THE BATTERY WITHOUT RISK OF OVERCHARGING THE BATTERY.
USER FRIENDLY CONTROLS - ALL INTELLI-CHARGE CHARGERS FEATURE USER-FRIENDLY DISPLAYS SO YOU CAN QUICKLY CUSTOMISE THE CHARGE SETTINGS AND MONITOR THE CHARGER?S PERFORMANCE. WHAT?S MORE, THE CHARGERS REMEMBER THE LAST SETTINGS USED EVEN WHEN THE POWER HAS BEEN TURNED OFF.
LCD DISPLAY & REMOTE CONTROL - CONTROL AND MONITOR THE CHARGER?S PERFORMANCE FROM A REMOTE CONTROL DISPLAY, ALLOWING THE CHARGER TO BE MOUNTED OUT OF THE WAY AND OUT OF SIGHT. THE BATTERY CHARGER AND REMOTE ARE SYNCHRONISED FOR OPERATION EITHER LOCALLY OR BY REMOTE.
TEMPERATURE COMPENSATION - THE TEMPERATURE SENSOR MONITORS THE BATTERY TEMPERATURE AND ADJUSTS (COMPENSATES) THE CHARGER?S OUTPUT TO PREVENT OVERCHARGING. THIS IS IDEAL FOR BATTERIES USED IN WARMER CLIMATES OR ENVIRONMENTS.
SHORT CIRCUIT PROTECTION - PROJECTA INTELLI-CHARGE BATTERY CHARGERS FEATURE SHORT CIRCUIT PROTECTION, EVEN IN POWER SUPPLY MODE.
DESIGNED TO PREVENT THE OUTPUT LEADS FROM SPARKING DURING CHARGING FROM ACCIDENTAL REVERSE CONNECTION OR SHORT CIRCUIT, PROJECTA GIVES YOU PEACE OF MIND THAT THE CHARGER WILL REMAIN SAFE AT ALL TIMES.
SHOCK PROOF & DUST PROOF - CONSTRUCTED FROM EXTRUDED ALUMINIUM, INTELLI-CHARGE BATTERY CHARGERS ARE SHOCK-PROOF, DUST-PROOF AND HAVE BEEN RIGOROUSLY VIBRATION TESTED AND PASSED BOTH A MILITARY AND CARAVAN STANDARD. IN ADDITION, THE CIRCUIT BOARDS HAVE BEEN CONFORMAL COATED TO PROTECT AGAINST MOISTURE AND DUST AND OTHER ELEMENTS SO THEY ARE SUITABLE FOR USE IN A RANGE OF LOCATIONS.
2 YEAR WARRANTY - AUSTRALIAN DESIGNED AND ENGINEERED, QUALITY IS GUARANTEED AND ALL BATTERY CHARGERS INCLUDE A 2 YEAR COMPREHENSIVE WARRANTY.
SPECIFICATIONS:
OUTPUT VOLTAGE: 24V
OUTPUT CURRENT: 2,4,6,8A
MINIMUM START VOLTAGE: 4.5V
BACK DRAIN: 1mA
CHARGE CONTROL:
DESULPHATION: High Frequency Pulse charge up to 11V
SOFT START: Half the rated set current up to 24V
BULK Set current up to:
28.2V (GEL)
28.8V (AGM)
29.4V (WET)
29.4V (CALCIUM)
ABSORPTION Constant voltage until current drops to:
2 Amp setting: 0.3A
4 Amp setting: 0.6A
6 Amp setting: 0.9A
8 Amp setting: 1.2A
EQUALIZATION: Contact current (2.0A) up to 32V then hold for 1 hour or 12 hour timeout
ANALYSIS: Monitors battery for 90 sec
RECONDITION Contant current (0.3-1.2A) for 4 hours limited to:
28.2V (GEL)
28.8V (AGM)
32.0V (WET)
32.0V (CALCIUM)
FLOAT 27.4V
POWER SUPPLY:
SETVOLTAGE: 27.6V
MAXIMUM CURRENT: 8A
BATTERY CHARGE TIMES:
AUTOMOTIVE 24V 80-1000CCA 7-24 HRS
MARINE 24V 110-1300MCA 7-24 HRS
DEEP CYCLE 24V 14-160AH 7-24 HRS
TYPES OF BATTERIES Most types of lead acid batteries including GEL, AGM, WET CELL and CALCIUM
SIZE (MM): 190x81x168
WEIGHT: 1.8Kg
|
