Product Code:
PPH-51
AIR PLANISHING HAMMER 1.2MM MILD STEEL
500MM THROAT CAPACITY WITH AIR FOOT
PEDAL ANVILS 25,50,77MM AIR BPM 875-1350
|
|
|
|
|
Please enter a valid quantity |
|
|
|
|
 |
|
|
|
THE PPH-51 PLANISHING HAMMER HAS BEEN LONG USED IN METAL FABRICATION AND RESTORATION TO SMOOTH LARGE AREAS OF METAL AFTER IT HAS BEEN ROUGHLY SHAPED WITH A HAMMER AND SAND BAG. COMMON USES ARE FOR CUSTOM MOTORCYCLE GAS TANK AND FENDER MANUFACTURING, STREET ROD BODIES, PATCH PANELS FOR AUTO RESTORATION, REPAIR AND METAL SCULPTING.
THE POWER HEAD IS A HEAVY-DUTY AIRCRAFT RIVET GUN, STURDY STEEL FABRICATED FRAME WITH 500MM THROAT DEPTH, IS BEEFY ENOUGH TO SMOOTH 1.2MM MILD STEEL. A QUICK RELEASE ALLOWS THE LOWER SHAFT TO SLIDE DOWN, TO ACCEPT PANELS WITH DEEP FLANGES. THE POWER HEAD ADJUSTMENT CONTROLS THE INTENSITY FROM 875-1350 BLOWS PER MINUTE. A FOOT CONTROL STARTS AND STOPS THE HAMMERING WHILE BEING HOOKED UP TO COMPRESSED AIR.
INCLUDES Ø32MM FLAT TOP DIE, 25, 50 AND 76MM RADIUS ANVILS.
THE MACHINE WEIGH'S 25KG AND HAS BOLT HOLES TO BE EASILY SECURED TO FLOOR.
FEATURES:
- 500MM THROAT CAPACITY
- 1.2MM MILD STEEL CAPACITY
- WITH FLOOR STAND
- FOOT PEDAL OPERATION
- COMES WITH 25, 50, 76MM RADIUS ANVILS
- 875-1350 BLOWS/MINUTE
- 50 - 100PSI PRESSURE
- 4CFM AIR CONSUMPTION
- OVERALL HEIGHT: 1220MM
- THE FOOTPRINT OF THE MACHINE IS 750MM X 350MM
THROAT CAPACITY: 500MM
CAPACITY - MILD STEEL: 1.2MM
BLOWS PER MINUTE: 875 - 1350
RADIUS ANVILS: 25, 50, 76MM
AIR CONSUMPTION: 4CFM
WORKING HEIGHT: 965MM
|
