PETROL ENGINES DIGITAL HOUR METER NK-HS2-BK
SIZE OF UNIT 2.36 X 1.57 X 0.59 INCHES
NKTECH NK-HS2 INDUCTIVE HOUR METER FOR GAS ENGINE LAWN MOVER MARINE ATV MOTORCYCLE BOAT SNOWMOBILE DIRT BIKE OUTBOARD MOTOR GENERATOR WATERPROOF HOURMETER (BLACK)
NK-HS2 INDUCTIVE HOUR METER FOR MARINE, ATV, MOTORCYCLE, BOAT, DIRT SKI TRACK THE SERVICE LIFE OF YOUR VEHICLE-OIL CHANGES, VALVE, ADJUSTMENTS, SPARK PLUGS, ETC.
RECORDS AND DISPLAYS TO 9,999.9 HOURS. STAND-BY TIME UP TO OVER 20,000 HOURS. HOURGLASS SYMBOL APPEARS AND FLASHES ON/OFF TO INDICATE COUNTING TIME.
AUTOMATIC ROLL OVER RESOLUTION 0.1 HOUR. 100% EPOXY ENCAPSULATED CASING RESISTS WATER, SHOCK, STAND FIRE OF 85?.
EASY INSTALLATION-PEEL & STICK, NO WIRING NECESSARY, OR ATTACH WITH ENCLOSED HARDWARE.
NO BATTERY REQUIRED-CONNECTS TO SPARK PLUG WIRE. WORKS ON ANY GAS ENGINE.
HOUR METER INSTALLATION METHOD -
1. WRAP THE INCLUDED PICK-UP WIRE AROUND THE SPARK PLUG WIRE FIVE TIMES. START WRAPPING THE PICK-UP WIRE ABOUT 4CM FROM THE END OF SPARK PLUG BOOT USE THE INCLUDED ZIP TIE TO SECURE THE PICK-UP WIRE WRAPPING AS SHOWN IN THE PHOTO RIGHT.
2. BEFORE CONTINUING THE INSTALLATION, INSERT THE PICK-UP WIRE INTO THE REAR OF THE METER. START THE MOTOR TO MAKE SURE THE METER IS PICKING UP THE IGNITION SIGNAL. IF IT SI, THIS WILL ACTIVATE THE TIMER ON THE METER AND THE ICON ON TEH LEFT OF THE LCD WILL FLASH. YOU'LL HAVE TO WAIT AT LEAST 6 MINUTES FOR THE TIMER TO INCREASE THE TIMER DISPLAY (1/10TH OF AN HJOUR). IF IT IS NOT PICKING UP THE IGNITION SIGNAL, SLIDE THE PICK-UP WRAP CLOSER TO THE SPARK PLUG BOOT.
3. IF THE METER IS SUCCESSFULLY PICKING UP THE SPARK SIGNAL, RUN AND ZIP TIE THE PICK-UP ALONG ONE OF THE THROTTLE CABLES. MAKE SURE THE PICK-UP WIRE CAN NOT MAKE CONTACT WITH THE ENGINE. ALSO, MAKE SURE YOU LEAVE ENOUGH SLACK (ABOUTY 8CM) SO REMOVING THE SPARK PLUG WIRE IS POSSIBLE. KEEP IN MIND THE GENERAL LOCATION OF FINAL MOUNTING LOCATION ON THE FRAME SPARE.
4. SECURRING METHOD:
A) DRILLING INTO YOUR FRAME WITH A 2.5MM SOCKET, THEN SECURE IT TO THE FRAME COMING WITH TWO PICK-UP SCREWS.
B) USING PADDED DOUBLE-SIDED TAPE ON THE BACKSIDE OF THE METER AND SECURED IT TO THE FRAME SPAR WITH ZIP TIES.
THAT'S ALL THERE IS TO THE UINSTALLATION. NOW YOU'RE SET TO ACCURATELY TRACK YOUR MAINTENANCE. DON'T FOPRGET TO RECOPRD THE METER WHEN PERFORMING MAINTENANCE.
|
