*NLA HAND TAP 1" X 11 NPT BOTTOMING
Click on image for larger photo
Product Code: M2453340

HAND TAP "1 X 11 NPT BOTTOMING SUTTON
THREAD LENGTH: 43.75MM (1 3/4")
OVERALL LENGTH: 93.7MM (3 3/4")
Border Image Border Image
Shop Price: $78.00
Web Price: $78.00  inc tax

Availability: In Stock
Quantity:
Weight: 0.18 KG
Border Image Border Image
SHANK DIAMETER: 1.125
PITCH MM: 11.1/2
SIZE: 1
NO. OF FLUTES: 4
TAPPING DRILL SIZE: 1.9/64
TYPE: B

NPT (TAPER PIPE)
- BOTTOMING LEAD ONLY

STEEL- BRASS & BRONZE : LUBRICANT REQUIRED MEDIUM OIL
ALUMINIUM : LUBRICANT REQUIRED KEROSENE
CAST IRON : LUBRICANT REQUIRED DRY OR SOLUBLE OIL
PLASTIC : LUBRICANT REQUIRED DRY

TAPS ARE USED FOR CUTTING INTERNAL THREADS IN PREDETERMINED HOLES.
THESE PERFORM BEST IN MATERIALS WHERE THE CUTTING ACTION RESULTS IN CHIPS WHICH BREAK UP READILY AND DO NOT PRESENT PROBLEMS OF CHIP DISPOSAL.
TAPER FOR QUICK EASY START, WILL NOT CUT TO BOTTOM OF HOLE
SECOND TO INCREASE THE SIZE OF THE CUT
BOTTOM TO FOLLOW THROUGH AND CUT RIGHT TO THE BOTTOM

GUIDELINES FOR USE:
- SECURE WORKPLACE & DRILL HOLE USING CORRECT SIZE TAPPING DRILL
- SELECT SUITABLE LUBERICANT
- SECURE TAP IN WRENCH & PLACE TAP SQUARELY IN HOLE
- USE DOWNWARD PRESSURE & TURN CLOCKWISE UNTIL RESISTANCE IS FELT
- ONCE STARTED TAP WILL DRAW ITSELF INTO THE WORKPLACE
- SCREW THE TAP SLOWLY INTO THE HOLE, BACKING OFF OCCASSIONALLY WHEN TAP BECOMES DIFFICULT TO TURN
***NEVER FORCE TAP - BREAKAGE MAY RESULT***
***ALWAYS WEAR EYE PROTECTION***
